MIN. BOOM LENGTH: 70′
MAX. BOOM LENGTH: 250′
MAX. TIP HEIGHT: 335′
MAX. HOOK HEIGHT: 321.5′ +/- 2.5′
MIN. FIXED JIB LENGTH: 40′
MAX. FIXED JIB LENGTH: 120′
OFFSET ANGLES: 5°, 30°
MAX. TIP HEIGHT: 393′
MAX. HOOK HEIGHT: 379.5′ +/- 2.5′
MIN. LUFFING JIB LENGTH: 70′
MAX. LUFFING JIB LENGTH: 240′
MAX. TIP HEIGHT: 545′
MAX. HOOK HEIGHT: 379.5′ +/- 2.5′
MIN. BOOM, FULL COUNTERWEIGHT: 293,000 lbs
MIN. BOOM, LOAD MOMENT: 11,720 kip/ft
MAX. BOOM, FULL COUNTERWEIGHT: 179,100 lbs
MAX. BOOM, LOAD MOMENT: 7,164 kip/ft
