MIN. BOOM LENGTH: 38′
MAX. BOOM LENGTH: 115′
MAX. TIP HEIGHT: 126′
MAX. HOOK HEIGHT: 116′
FULLY EXTENDED OUTRIGGER FOOTPRINT: 23.8′ x 24.0′
MAX. OUTRIGGER LOAD: 90,500 lbs
MIN. BOOM EXTENSION LENGTH: 35′
MAX. BOOM EXTENSION LENGTH: 90′
OFFSET ANGLES: 2°, 15°, 30°, 45°
MAX. TIP HEIGHT: 217′
MAX. HOOK HEIGHT: 207′
MIN. BOOM, FULL COUNTERWEIGHT: 26,400 lbs
MAX. BOOM, FULL COUNTERWEIGHT: 25,700 lbs
