MIN. BOOM LENGTH: 40′
MAX. BOOM LENGTH: 150′
MAX. TIP HEIGHT: 161′
MAX. HOOK HEIGHT: 150′
FULLY EXTENDED OUTRIGGER FOOTPRINT: 26.0′ x 26.0′
MAX. OUTRIGGER LOAD: 132,000 lbs
MIN. BOOM EXTENSION LENGTH: 10′
MAX. BOOM EXTENSION LENGTH: 91′
OFFSET ANGLES: 2°, 45°
MAX. TIP HEIGHT: 253′
MAX. HOOK HEIGHT: 242′
MIN. BOOM, FULL COUNTERWEIGHT: 51,500 lbs
MAX. BOOM, FULL COUNTERWEIGHT: 30,000 lbs
